    Harken 244 Micro Fiddle with V Jam
    Harken 244

    Micro Fiddle with V Jam

    The Harken 244 Micro Fiddle with V Jam, sold at Harken's advertised price by One Design Rigging, an authorized Harken dealer. Ships in about 3 business days.

    $43.95List $49.90

    Ships in about 3 business days, plus transit.

    Returns within 30 days of delivery. Returns and exchanges

    Part number
    244
    UPC
    097653009726
    Harken catalogue
    Page 34

    Harken 2026 catalogue, page

    Open the whole catalogue (PDF)
    Family
    Small Boat and Midrange

    Specifications

    Sheave diameter
    22 mm7/8 in
    Length
    89 mm3 1/2 in
    Weight
    57 g2 oz
    Shackle pin diameter
    5 mm3/16 in
    Max line diameter
    6 mm1/4 in
    Max working load
    159 kg350 lb
    Breaking load
    544 kg1200 lb

    From the Harken 2026 catalogue.

    CAD drawings
    End view (DWG) Side view (DWG)
