    Harken 3248 100mm Double Block
    Harken 3248

    100mm Double Block

    The Harken 3248 100mm Double Block, sold at Harken's advertised price by One Design Rigging, an authorized Harken dealer. Ships in about 3 business days.

    $1,519.95List $1,726.80

    Ships in about 3 business days, plus transit.

    Returns within 30 days of delivery. Returns and exchanges

    Part number
    3248
    UPC
    097653296249
    Harken catalogue
    Page 55

    Harken 2026 catalogue, page

    Open the whole catalogue (PDF)
    Family
    Big Boat

    Specifications

    Sheave diameter
    100 mm3 15/16 in
    Length
    227 mm8 15/16 in
    Weight
    1284 g45.28 oz
    Shackle pin diameter
    12 mm1/2 in
    Max line diameter
    16 mm5/8 in
    Max working load
    4990 kg11000 lb
    Breaking load
    9979 kg22000 lb

    From the Harken 2026 catalogue.
